Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine
Heavy Duty Drilling Cum Tapping Machine

Heavy Duty Drilling Cum Tapping Machine

Price 40000.0 INR/ Unit

MOQ : 1 Unit

Heavy Duty Drilling Cum Tapping Machine Specification

  • Diameter
  • 25 mm
  • Motor Power
  • 2 HP
  • Noise Level
  • Low
  • Frequency
  • 50 Hz
  • Spindle Speed
  • Multiple speed options (up to 2600 RPM)
  • Cutting Area
  • 25 mm diameter
  • Machine Type
  • Drilling Cum Tapping Cum Milling Machine
  • Table Size
  • 540 x 250 mm
  • Features
  • Heavy duty construction, precision gearing, adjustable worktable, square model design, ISO & CE certified
  • Condition
  • New
  • Dimension (L*W*H)
  • 900 x 600 x 1700 mm
  • Product Type
  • Heavy Duty Drilling Cum Tapping Machine
  • Material
  • Cast Iron, Steel Components
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • CNC Or Not
  • No
  • Control System
  • Manual control
  • Voltage
  • 220/440V
  • Power
  • 2 HP
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 250 kg
  • Capacity
  • 25 mm (Drilling)
  • Color
  • Green
  • Usage & Applications
  • Heavy duty drilling, tapping, and milling operations in workshops, fabrication units, and production industries
  • Column Diameter
  • 85 mm
  • Base Size
  • 380 x 300 mm
  • Spindle Travel
  • 125 mm
  • Head Type
  • Square Head for rigid milling and tapping operations
  • Worktable Movement
  • Manual (X & Y axis)
  • Chuck Size
  • 1 inch
  • Maximum Milling Capacity
  • 12 mm
  • Model
  • RTD-25 Square Model
  • Machine Finish
  • Powder Coated



About Heavy Duty Drilling Cum Tapping Machine

Heavy Duty Drilling Cum Tapping Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent industrial machines for heavy-duty metal drilling, tapping and fabrication applications.


Versatile Design for Multiple Operations

The RTD-25 Square Model is engineered for rugged use in heavy-duty drilling, tapping, and milling. Its square head and adjustable worktable enhance operational flexibility, while the machine's precision gearing supports consistent, accurate results. Its construction ensures durability and minimal vibration, making it ideal for workshops and industrial settings.


Robust Construction and User-Friendly Features

Manufactured from high-grade cast iron and steel, the RTD-25 boasts a powder-coated finish for corrosion resistance. Manual worktable movement in both X and Y axes allows fine-tuned adjustments, and the straightforward manual control system ensures easy operation, even for semi-automatic processes.


Certified Performance for Industrial Needs

The RTD-25 holds both ISO and CE certifications, attesting to its quality and safety. With multiple spindle speeds up to 2600 RPM and a heavy-duty motor, it answers the call for demanding fabrication, ensuring both efficiency and operator safety in high-output environments.

FAQ's of Heavy Duty Drilling Cum Tapping Machine:


Q: How is the RTD-25 Square Model used in heavy-duty applications?

A: The RTD-25 Square Model is specifically designed for rigorous drilling, tapping, and milling operations by providing precision and stability through its square head and robust cast iron construction. Its 2 HP motor and manual worktable movement make it suitable for workshops, fabrication units, and industrial production lines.

Q: What materials can I process with this machine?

A: This machine is adept at handling cast iron, steel, and similar hard materials, thanks to its high-capacity spindle and sturdy frame. It is engineered for heavy-duty use, making it ideal for a wide range of metalworking tasks.

Q: When is manual worktable movement beneficial?

A: Manual X and Y axis movement allows operators to have full control over workpiece positioning, enabling precision alignment for drilling, tapping, or milling. This is particularly advantageous in tasks that require fine adjustments and customization.

Q: Where can the RTD-25 be installed?

A: The RTD-25 is compact enough for workshops and industrial floors, requiring a footprint of approximately 900 x 600 mm. Its heavy-duty build and low-noise operation make it suitable for both small-scale workshops and large production facilities.

Q: What is the process for changing spindle speed on the machine?

A: Spindle speed on the RTD-25 can be manually adjusted through the provided controls. The operator selects the desired speed based on the material and operation type, allowing for versatility with multiple speed options up to 2600 RPM.

Q: How does this machine benefit my operation compared to standard drilling machines?

A: The RTD-25 Square Model's heavy-duty construction, precision gearing, and versatility for drilling, tapping, and milling provide greater reliability, accuracy, and longevity. Its ISO & CE certification ensures quality and safety, and the robust motor supports continuous, demanding use.
