Price 23000.0 INR/ Unit

MOQ : 1 Unit

Workshop Drilling Machine Specification

  • Spindle Speed
  • Variable, Geared (12 to 1600 RPM typical for this class)
  • Noise Level
  • Low (mechanically geared operation)
  • Cutting Area
  • Suitable for 40 mm hole diameter in metals
  • Motor Power
  • 1.5 HP to 2 HP
  • Frequency
  • 50 Hz
  • Machine Type
  • Pillar Drill Machine (RTD-17 H Geared - Round Model)
  • Dimension (L*W*H)
  • Approx. 900 x 500 x 1800 mm
  • Table Size
  • 400 mm Diameter (Round Table)
  • Diameter
  • 40 mm (Pillar Drilling Capacity)
  • Features
  • Geared Drive, High Stability, Adjustable Table Height, Robust Cast Iron Construction
  • Condition
  • New
  • Product Type
  • Workshop Drilling Machine
  • Material
  • Cast Iron, Mild Steel
  • Computerized
  • No
  • Automatic Grade
  • Manual
  • CNC Or Not
  • Not CNC
  • Control System
  • Hand Operated Mechanical Controls
  • Voltage
  • 220V - 440V
  • Power
  • 1.5 HP to 2 HP
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 200-240 kg
  • Capacity
  • 40 mm (1.5 inches)
  • Color
  • Green (Body) / Black (Table)
  • Usage & Applications
  • Industrial and Workshop Drilling, Metalworking
  • Application Material
  • Steel, Cast Iron, Non-Ferrous Metals
  • Mounting Type
  • Floor Mounted
  • Column Diameter
  • 87 mm
  • Spindle Travel
  • Approx. 150 mm
  • Distance from Spindle to Base
  • 900 mm
  • Model
  • RTD-17 H (Geared - Round Model)
  • Feed Type
  • Manual / Lever Feed
  • Height of Machine
  • Approx. 1800 mm
  • Body Finish
  • Powder Coated
  • Drill Chuck Size
  • Up to 16 mm (B16 taper)



About Workshop Drilling Machine

Workshop Drilling Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent drilling machines for workshops, engineering, fabrication and general metal drilling.

Robust Geared Drive for Reliable Operation

The RTD-17 H drilling machine is built with a mechanically geared drive system, delivering consistent torque and variable speed for efficient drilling across a variety of metals. Its cast iron structure enhances stability and reduces operational noise, making it suitable for busy industrial environments.


Flexible Drilling Capacity and Adjustable Table Height

Designed to support holes up to 40 mm in diameter, this pillar drill is suitable for steel, cast iron, and non-ferrous materials. The height-adjustable round table allows easy adaptation to different workpiece sizes, improving workflow efficiency and precision during drilling tasks.


Ease of Use and Maintenance

With a straightforward manual lever-feed and hand-operated mechanical controls, the RTD-17 H simplifies operation for workshop and industrial users. The powder-coated finish ensures lasting protection against wear, while the non-CNC, manual design reduces maintenance efforts and costs.

FAQ's of Workshop Drilling Machine:


Q: How is the RTD-17 H Workshop Drilling Machine operated and controlled?

A: The RTD-17 H is operated manually using lever-feed and hand-operated mechanical controls, providing users with direct control over drilling speed and feed rate. No computerized or CNC systems are involved, making it straightforward for workshop use.

Q: What types of materials can this drilling machine handle?

A: This machine is suitable for drilling steel, cast iron, and non-ferrous metals, supported by its robust construction and variable speed gearing for optimal penetration and finish on these materials.

Q: When should you choose the RTD-17 H for workshop or industrial drilling applications?

A: Select the RTD-17 H when you require a reliable, floor-mounted pillar drill for large or deep hole drilling in metalwork. Its high stability, adjustable table, and geared speed range are ideal for professional and industrial settings.

Q: Where is the RTD-17 H typically installed and used?

A: The machine is designed for installation in workshops, factories, and metalworking facilities. It is floor-mounted for maximum stability and can accommodate heavy-duty drilling operations in both small and large workspaces.

Q: What is the process for mounting and setting up the RTD-17 H machine?

A: This pillar drill is securely floor-mounted and requires connection to a suitable electric supply (220V-440V). The table height can be adjusted, and the drill chuck fits up to 16 mm bits with B16 taper, making setup efficient for immediate use.

Q: How does the variable geared drive benefit drilling operations?

A: The geared drive enables variable spindle speeds (12-1600 RPM), allowing users to adjust speed according to the material and hole size. This versatility makes the machine effective for both high-precision and heavy-duty drilling.

Q: What are the usage advantages and benefits of the RTD-17 H model?

A: Key benefits include high stability due to its cast iron pillar, low noise operation, adjustable table height for flexibility, and powder-coated protection for durability. Its manual controls and geared speeds give precise results across industrial and workshop projects.
