Price 23000.0 INR/ Unit

MOQ : 1 Unit

Pillar Drill Specification

  • Features
  • Heavy Duty Geared Head, Precision Machining, Easy Operation, Durable Construction
  • Spindle Speed
  • Multi Speed (typically 8-12 speed settings, 80-2100 rpm)
  • Condition
  • New
  • Machine Type
  • RTD-15 L (Geared - Square Model)
  • Motor Power
  • 0.75 kW to 1.5 kW
  • Diameter
  • 25 mm (Drilling Capacity)
  • Frequency
  • 50 Hz
  • Table Size
  • Approx 250 x 250 mm
  • Dimension (L*W*H)
  • Approx 900 x 500 x 1600 mm
  • Cutting Area
  • 25 mm Max Diameter
  • Noise Level
  • Low
  • Product Type
  • Pillar Drill Machine
  • Material
  • Cast Iron & Mild Steel
  • Computerized
  • No
  • Automatic Grade
  • Semi Automatic
  • CNC Or Not
  • No
  • Control System
  • Manual
  • Voltage
  • 220-240 V
  • Power
  • 0.75 kW to 1.5 kW
  • Power Source
  • Electric
  • Weight (kg)
  • Approx 150-180 kg
  • Capacity
  • 25 mm (1 inch) drilling capacity
  • Color
  • Green (Machine Tool Paint)
  • Usage & Applications
  • Drilling, Tapping, Reaming for metal, wood, and plastic industries
  • Type of Transmission
  • Geared Drive
  • Base Size
  • Approx 410 x 270 mm (workable area)
  • Distance Spindle to Base
  • Approx 1000 mm
  • Table Movement
  • Vertical & Rotational
  • Column Diameter
  • 70-75 mm
  • Finish
  • Powder Coated
  • Distance Spindle to Table
  • Approx 600 mm
  • Quill Diameter
  • Approx 46 mm
  • Spindle Travel
  • Approx 140 mm
  • Chuck Size
  • Up to 16 mm
  • Feed System
  • Hand Lever
  • Primary Operation
  • Precision Drilling and Boring



About Pillar Drill

Pillar Drill manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent industrial pillar drilling machines for metalworking, fabrication and workshop drilling.

Precision and Durability Combined

Engineered from cast iron and mild steel, the RTD-15 L Pillar Drill is built to withstand rigorous industrial demands. Its powder-coated finish enhances resistance to corrosion, while the heavy-duty geared head ensures reliable transmission. Precision machining delivers accurate results, making this drill suitable for both small and large-scale operations.


Versatile Operation for Multiple Industries

The drill's vertical and rotational table movement, coupled with up to 16 mm chuck size and multi-speed settings, accommodates a variety of materials and processes. Whether used for drilling, tapping, or reaming in metal, wood, or plastic, this machine adapts seamlessly, thanks to its easy operation and adjustable spindle speeds.


Efficiency and Low Noise

This pillar drill features a low-noise motor and manual hand lever feed system, ensuring quiet, smooth operation. Its semi-automatic grade and manual control system make it user-friendly, while the geared drive offers consistent performance. The substantial workable base and table enhance productivity and operator comfort.

FAQ's of Pillar Drill:


Q: How does the RTD-15 L Pillar Drill achieve precision during drilling and boring operations?

A: Precision is achieved through its heavy-duty geared head, precision machining, and robust column and quill design. The machine's construction minimizes vibrations, and the multi-speed spindle allows for customized speed selection, improving accuracy for various materials and hole sizes.

Q: What is the maximum drilling capacity of this pillar drill, and which materials can it process?

A: The RTD-15 L Pillar Drill offers a maximum drilling capacity of 25 mm (1 inch) and is suitable for use with metals, wood, and plastics. Its design caters to diverse industry requirements across manufacturing, workshop, and fabrication applications.

Q: When should I use the table's vertical and rotational movement features?

A: The vertical and rotational table movement is ideal when you need to adjust the workpiece position for complex drilling angles, multi-hole patterns, or reaming operations. It facilitates precise alignment and improves accessibility, especially for larger or irregularly shaped materials.

Q: Where can this pillar drill be installed and used effectively?

A: This pillar drill is best suited for industrial workshops, manufacturing units, maintenance departments, and educational institutions where consistent heavy-duty drilling or boring on metals, wood, or plastics is required. Its sturdy base and manageable dimensions allow placement on work floors, benches, or dedicated machining stations.

Q: What is the process for operating the RTD-15 L Pillar Drill safely and efficiently?

A: To operate safely, ensure the workpiece is securely clamped on the table or base. Select the appropriate spindle speed and chuck size for your material, adjust the table position, and use the manual feed lever to advance the tool. Always wear safety equipment and check the motor and electrical connections before starting.

Q: How does the geared drive transmission benefit the operation of this pillar drill?

A: The geared drive transmission provides smooth power delivery and enables the spindle to operate across multiple speed settings, efficiently adapting to the requirements of different materials and hole sizes. This mechanism enhances durability and ensures consistent drilling performance.

Q: What advantages does this pillar drill offer compared to other machines in its class?

A: Key advantages include heavy-duty construction, low noise level, versatile spindle speed range, precision machining, and easy, manual operation. Its semi-automatic, geared design and powder-coated finish ensure reliability, minimal maintenance, and longevity even in demanding industrial environments.
