Variable Speed Belt Grinder Machine

Get a Price/Quote

Variable Speed Belt Grinder Machine Specification

Model
6 x 80 - Three Head Series

Rotation
Both Directions (Forward & Reverse)

Product Type
Automatic Belt Grinder

General Use
Heavy Duty Industrial Belt Grinding

Material
Mild Steel Body

Type
Three Head

Capacity
Continuous Heavy Duty Grinding

Weight (kg)
Approx. 1000 kg

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
PLC Control Panel

Table Size
Custom/Optional

Table Slide Way
Precision Linear Guides

Grinding Wheel Size
6 x 80 (Belt Size)

Grinding Wheel Speed
0 - 2,800 RPM (Variable)

Grinding Length
Up to 80 inches

Floor Space
Approx. 2400 mm x 900 mm

Spindle Speed
Variable Speed via VFD

Power
7.5 HP (for three-head)

Voltage
415V AC 3 Phase

Dimension (L*W*H)
2400 x 900 x 1600 mm (approx.)

Feature
ISO 9001:2015 & CE Certified, Robust Construction, Variable Speed

Color
Orange and Blue

Heads
3 (Three Head Automatic)

Safety Features
Full Cover Guards & Emergency Stop Switch

Coolant System
Optional

Belt Changing Mechanism
Quick Belt Change Facility

Body Finish
Powder-Coated for Corrosion Resistance

Noise Level
Low Noise Operation

Belt Tracking
Manual and Automatic Tracking System

Application
Sheet Metal, Pipe, and Profile Grinding

Dust Extraction
Provided with Enclosed Hood

Drive Type
Direct Drive Heavy Duty Motor

About Variable Speed Belt Grinder Machine

Variable Speed Belt Grinder Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent machines with variable-speed control for precision metal finishing.

Versatile Three-Head Design

The grinder's three automatic grinding heads allow for efficient and simultaneous material processing, significantly reducing production time. This feature is especially beneficial for large-scale manufacturers working with diverse materials, including sheet metal and pipe sections. The robust construction and direct-drive motor ensure dependable, long-term performance for continuous industrial use.

Advanced Control & Safety Features

Equipped with a PLC control panel, the machine offers variable spindle speeds (0 - 2,800 RPM) and bi-directional rotation to suit various grinding tasks. Full cover guards, an emergency stop switch, and low-noise operation maintain a safe and comfortable working environment, meeting ISO 9001:2015 and CE certification standards.

Efficient Operation & Maintenance

With a quick belt-changing mechanism and precision linear guides for table movement, the grinder is built for ease of use and minimal downtime. The option for a coolant system and the included enclosed dust extraction hood help maintain cleanliness, part quality, and machine longevity. The powder-coated finish protects against corrosion, even under harsh industrial conditions.

FAQ's of Variable Speed Belt Grinder Machine:

Q: How does the quick belt change mechanism on the Variable Speed Belt Grinder work?

A: The grinder features an easy-access system that enables operators to replace sanding belts rapidly without extensive downtime. Simply release the tension lever, remove the used belt, align a new one, and secure the mechanism-reducing tool changeover times and boosting productivity.

Q: What are the primary applications for the 6 x 80 - Three Head Series Belt Grinder?

A: This machine is optimized for continuous heavy-duty grinding of sheet metal, piping, and industrial profiles. It's commonly used in fabrication shops, metal finishing plants, and manufacturing environments where high-speed, consistent surface finishing and material preparation are essential.

Q: Where can the belt grinder be installed, and what are its space requirements?

A: Given its industrial-grade design and dimensions of approximately 2400 x 900 x 1600 mm, the grinder is best suited for workshop floors with ample space and adequate ventilation. Facilities should provide a 415V three-phase electrical connection and allocate around 2400 mm x 900 mm of floor space for optimal operation and accessibility.

Q: What types of grind settings and speed variations does the grinder support?

A: Thanks to its PLC control panel and Variable Frequency Drive (VFD), users can adjust grinding wheel speeds from 0 to 2,800 RPM. Both forward and reverse rotation options allow for tailored surface treatments, accommodating a wide spectrum of materials and grinding requirements.

Q: How does the dust extraction and noise reduction system benefit operators?

A: The enclosed dust extraction hood captures grinding debris efficiently, minimizing airborne particles and maintaining a cleaner workspace. Coupled with the machine's low-noise operation, these features create a healthier, more comfortable, and compliant working environment for operators.

Q: What are the available safety features included with the grinder?

A: Safety is prioritized with full-cover guards around moving components, an emergency stop switch for instant shutdown, and a robust powder-coated body. These features greatly reduce the risk of operator injury while ensuring durable, long-lasting machine performance.

Q: When should the optional coolant system be considered?

A: A coolant system is recommended for applications involving elevated temperatures or when processing heat-sensitive materials. Employing coolant during intensive or continuous grinding helps prolong belt life, maintains part integrity, and enhances the overall quality of finished components.
