Price 23000.0 INR/ Piece

MOQ : 1 Piece

Pillar Type Drilling Machine Specification

  • Features
  • Heavy Duty Construction, Geared Drive, Precision Machining
  • Cutting Area
  • Suitable for up to 25 mm Diameter Holes
  • Table Size
  • 350 x 350 mm (Approx.)
  • Dimension (L*W*H)
  • 550 x 350 x 1600 mm (Approx.)
  • Frequency
  • 50 Hz
  • Diameter
  • Max Drilling Capacity: 25 mm
  • Condition
  • New
  • Spindle Speed
  • 3 Speed / 1440 RPM - 2800 RPM (Approx.)
  • Noise Level
  • Low
  • Machine Type
  • Pillar Drill, RTD-16 L (Geared - Round Model)
  • Motor Power
  • 1 HP / 0.75 kW
  • Product Type
  • Pillar Type Drilling Machine
  • Material
  • Cast Iron and Steel
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • CNC Or Not
  • No
  • Control System
  • Manual Lever Operation
  • Voltage
  • 220V / 415V (Depending on Motor)
  • Power
  • 0.75 kW - 1.5 kW (Approx.)
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 120-150 kg
  • Capacity
  • 25 mm (Drilling)
  • Color
  • Green / Customized
  • Usage & Applications
  • Metal Drilling, Workshop, Industrial Applications
  • Drill Head Tilting
  • 45 L/R
  • Base Size
  • 475 x 325 mm (Approx.)
  • Spindle Travel
  • 125 mm (Approx.)
  • Number of Speed Settings
  • 3 to 9 (Model Dependent)
  • Column Diameter
  • 73 mm (Approx.)
  • Maximum Distance Spindle to Base
  • 915 mm (Approx.)
  • Model Number
  • RTD-16L
  • Maximum Distance Spindle to Table
  • 680 mm (Approx.)
  • Coolant System
  • Provision Available (Optional)


Pillar Type Drilling Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Delivery Time
  • 5-7 Days


About Pillar Type Drilling Machine

Pillar Type Drilling Machine manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent industrial machines for precision metal drilling and fabrication.


Versatile Performance for Diverse Applications

Ideal for workshops and industrial environments, the RTD-16L excels in drilling metals with its maximum capacity of 25 mm. The machine's geared mechanism and adjustable spindle speeds facilitate smooth tool operation for different materials and thicknesses. The robust build, combined with a semi-automatic grade and manual lever control, allows for just the right balance between user control and efficient, repeatable drilling.


Precision and Durability Built In

Featuring a sturdy cast iron and steel frame, this machine minimizes vibration and enhances accuracy during operation. The heavy-duty construction and precision-machined components ensure long-term use with minimal maintenance. The ability to tilt the drill head up to 45 both left and right adds a layer of flexibility, accommodating a range of drilling angles and project demands.

FAQ's of Pillar Type Drilling Machine:


Q: How is the RTD-16L Pillar Type Drilling Machine operated?

A: The RTD-16L is manually operated using a lever system, allowing the operator to control spindle movement precisely during drilling. It is not computerized or CNC-based, making it ideal for hands-on control in workshop settings.

Q: What materials and applications is this drilling machine suitable for?

A: Constructed from durable cast iron and steel, the RTD-16L is designed for drilling metals and is well-suited for workshop and industrial use, including fabrication, metalworking, and maintenance operations.

Q: When should the coolant system option be used?

A: The coolant system provision is recommended for demanding drilling tasks or when working with hard metals, as it helps reduce heat buildup, prolong tool life, and ensure smoother drilling performance.

Q: Where can I use the RTD-16L Pillar Drilling Machine?

A: This machine is intended for use in workshops, manufacturing units, and industrial environments where precise and heavy-duty drilling operations are required.

Q: What are the available speed settings and how do they benefit operation?

A: Depending on the specific model, the RTD-16L offers 3 to 9 spindle speed options ranging from 1440 RPM to 2800 RPM. This versatility enables optimal cutting speeds for various materials, improving both efficiency and drill bit longevity.

Q: How does the drill head tilting function enhance usability?

A: The 45-degree left/right tilting drill head allows users to perform angled drilling, making the machine highly adaptable for tasks that require more than straightforward vertical holes.

Q: What are the benefits of the machine's construction and design?

A: The heavy-duty, precision-machined structure of the RTD-16L ensures low noise, minimal vibration, greater operational safety, and consistency in drilling results, making it a reliable addition to any professional workshop.
