Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine
Heavy Duty Drilling Machine

Heavy Duty Drilling Machine

Price 23000.0 INR/ Unit

MOQ : 1 Unit

Heavy Duty Drilling Machine Specification

  • Frequency
  • 50 Hz
  • Spindle Speed
  • 70-2000 RPM (Variable/Multiple Speeds)
  • Dimension (L*W*H)
  • Base: 580mm x 370mm approx
  • Motor Power
  • 1 HP
  • Cutting Area
  • 25 mm Diameter
  • Machine Type
  • Pillar Drilling Machine
  • Condition
  • New
  • Table Size
  • 355 mm (14) Diameter (Round Table)
  • Diameter
  • 25 mm Drilling Capacity
  • Noise Level
  • Low
  • Features
  • Geared, Sturdy Construction, ISO & CE Certified, High Accuracy, Heavy Duty Model
  • Product Type
  • Heavy Duty Drilling Machine
  • Material
  • Cast Iron Body, Steel Parts
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • CNC Or Not
  • No
  • Control System
  • Manual
  • Voltage
  • 220V-440V (as per requirement)
  • Power
  • 1 HP (0.75 kW)
  • Power Source
  • Electric
  • Weight (kg)
  • Approx 120-140 Kg
  • Capacity
  • 25 mm (Drilling Capacity in Steel)
  • Color
  • Green
  • Usage & Applications
  • Drilling, Boring, Reaming for Steel, Cast Iron, and Metalwork
  • Mounting Type
  • Floor Standing
  • Column Diameter
  • 87 mm
  • Max Distance Spindle to Base
  • 730 mm
  • Spindle Travel
  • 165 mm
  • Number of Spindle Speeds
  • 8 or 12 (Depending on Configuration)
  • Usage Environment
  • Industrial/Workshop
  • Max Distance Spindle to Table
  • 475 mm
  • Overall Height
  • Approx. 1600 mm
  • Model
  • RTD-23 H (Geared - Round Model)
  • Pillar Type
  • Round
  • Base Size
  • 580 mm x 370 mm



About Heavy Duty Drilling Machine

Heavy Duty Drilling Machine manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent industrial drilling machines for demanding metalworking and fabrication applications.

Precision Engineered for Heavy Duty Tasks

The RTD-23 H Geared Pillar Drilling Machine excels at tackling heavy-duty operations in metalworking environments. Its robust cast iron body and steel components support precise drilling, boring, and reaming of steel, cast iron, and similar metals with minimal vibration and noise, ensuring reliable results shift after shift.


Versatility and Adaptability for Industrial Needs

With adjustable spindle speeds (70-2000 RPM) and an 8 or 12-speed gearbox configuration, this machine adapts seamlessly to different material types and drilling requirements. Its spacious base and table provide ample work area while its round pillar design promotes stability and accuracy during demanding operations.

FAQ's of Heavy Duty Drilling Machine:


Q: How is the RTD-23 H heavy duty drilling machine operated?

A: The RTD-23 H drilling machine is manually operated through a semi-automatic control system, with all main functions adjusted by the user for optimal precision. It does not use CNC or computerized systems, ensuring user control over each drilling task.

Q: What materials and applications are suitable for this drilling machine?

A: This machine is specially designed for drilling, boring, and reaming tasks on steel, cast iron, and other metals, making it ideal for industrial workshops and metal fabrication environments requiring high accuracy and durability.

Q: When should I adjust the spindle speed, and how is it done?

A: Spindle speed should be adjusted based on material hardness and drill bit size for efficient operation. This is done manually using the machine's gear system, offering 8 or 12 speeds within a 70-2000 RPM range, depending on the chosen configuration.

Q: Where can the RTD-23 H drilling machine be installed?

A: This model is floor standing and designed for installation in industrial settings, machine shops, or workshops with a solid, level floor to support its weight and provide stable operation during extended use.

Q: What are the benefits of choosing a geared, heavy duty model like the RTD-23 H?

A: Choosing the RTD-23 H ensures reliable performance, higher drilling accuracy, and durability even under continuous heavy use. Its geared mechanism allows for efficient power transmission, and ISO & CE certifications guarantee adherence to quality and safety standards.

Q: How do I maintain the RTD-23 H to ensure optimal performance?

A: Regular maintenance, such as lubrication of moving parts, checking for wear on belts and gears, and keeping the machine clean of metal shavings, will help maintain accuracy and prolong the machine's service life.

Q: What power and voltage requirements are needed for installation?

A: The machine requires an electric supply of 220V to 440V as per user requirements and operates with a 1 HP (0.75 kW) motor, standard for most industrial workshops.
