Multi Head Belt Grinder Machine

Get a Price/Quote

Multi Head Belt Grinder Machine Specification

Rotation
Unidirectional

Model
Ramato 3 Head 6 x 80 Series

Product Type
Three Head Automatic Belt Grinder

General Use
Heavy Duty Metal Surface Finishing and Grinding

Material
MS, SS and Heavy Duty Frame Construction

Type
Surface Belt Grinding

Capacity
Heavy Duty / Continuous Operation

Weight (kg)
Approx. 950-1200 kg

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
Electric Control Panel

Grinding Wheel Size
6 inch x 80 inch (Belt Size)

Grinding Wheel Speed
Customizable as per application

Grinding Length
80 inch

Floor Space
Estimated 2100 mm x 900 mm

Spindle Speed
1440 RPM or as per requirement

Power
Approx. 5 HP per head

Voltage
415V / 380V, 3 Phase, 50 Hz

Dimension (L*W*H)
Approx. 2100 mm x 900 mm x 1850 mm

Feature
ISO 9001:2015 & CE Certified; High Productivity; Easy Operation; Reduced Labour

Color
Blue & Orange

Dust Extraction
Provision available for optional dust collector

Noise Level
Moderate, within industrial safety range

Motor Type
Standard 3 Phase Induction Motor

Installation
Floor mounted, ready-to-use

Belt Changing
Quick-change system

Number of Heads
3 (Multi-head series available)

Working Speed
Variable (Depends on belt and motor)

Belt Tensioning
Manual / Pneumatic adjustment based on model

Safety Features
Enclosed guards; Emergency stop

Belt Drive System
Heavy duty pulley with protected safety guard

Application
Deburring, Surface Grinding, Finishing, Edge Rounding

About Multi Head Belt Grinder Machine

Multi Head Belt Grinder Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent multi-head abrasive belt machines for automated metal finishing.

Cutting-Edge Efficiency for Metal Finishing

Engineered for durability and high-output, the Multi Head Belt Grinder Machine streamlines surface finishing processes. Its three powerful heads work in unison, achieving uniform, precise results on materials like mild and stainless steel. Floor-mounted and ready to use, this industrial workhorse maximizes productivity while minimizing manual labor.

Precision and Safety in Every Operation

With features such as heavy-duty pulleys, enclosed safety guards, and an emergency stop, this grinder prioritizes user protection without compromising performance. Manual or pneumatic belt tensioning and a quick-change belt system ensure seamless workflow, making maintenance simple and safe in demanding environments.

Flexible Performance for Diverse Applications

From deburring and edge rounding to mirror finishing, this machine adapts to a wide spectrum of grinding tasks. Adjustable working speeds and spindle speeds up to 1440 RPM mean you can tailor operations to match specific application requirements, guaranteeing superior surface quality for each project.

FAQ's of Multi Head Belt Grinder Machine:

Q: How is the belt tensioned on the Multi Head Belt Grinder Machine?

A: Depending on the specific model, the belt tensioning system can be adjusted manually or pneumatically, allowing operators to select the best method for their workflow and ensuring consistent belt pressure for optimal grinding performance.

Q: What types of applications can this belt grinder handle?

A: This machine is suitable for a variety of metal surface operations, including deburring, edge rounding, surface grinding, and finishing. Its heavy-duty construction makes it ideal for continuous use in industrial settings, working effectively with both mild and stainless steel.

Q: When should I change the grinding belt, and how is it done?

A: The grinding belt should be changed when you notice reduced cutting efficiency or excessive wear. Thanks to the machine's quick-change mechanism, belts can be replaced swiftly and safely with minimal downtime, ensuring you maintain productivity during long shifts.

Q: Where should the Multi Head Belt Grinder Machine be installed?

A: This is a floor-mounted, industrial-grade machine designed for factory and workshop environments. It requires a dedicated space of approximately 2100 mm by 900 mm and access to a 3-phase power supply.

Q: What benefits does a multi-head configuration provide over a single-head grinder?

A: Having multiple grinding heads enables simultaneous multi-stage processing, which accelerates production, ensures uniform surface finishes, reduces labor intervention, and supports high-volume operations with consistent results.

Q: How does the dust extraction provision improve the working environment?

A: The machine includes a provision for connecting an optional dust collector, which helps remove metal dust and particles during operation. This feature promotes a cleaner workspace, better air quality, and compliance with industrial safety standards.

Q: What are the key safety features included in this grinder?

A: User protection is prioritized through enclosed guards around moving parts, a heavy-duty safety guard over the pulley system, and an emergency stop button, all designed to reduce accidental contact and enhance operator safety.
