Multi Head Belt Grinder Machine

Name: Multi Head Belt Grinder Machine
Brand: Rajlaxmi Machine Tools
Price: 90000.0 INR
Availability: InStock

Price 90000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Multi Head Belt Grinder Machine Specification

Model
HM-4H-6X80

Rotation
Unidirectional

Product Type
Multi Head Belt Grinder

General Use
Industrial heavy-duty surface grinding and polishing

Material
Mild Steel Structure

Type
Four Head Automatic

Capacity
Suitable for continuous batch processing

Weight (kg)
Approx. 950 kg

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
Automatic Electric Panel

Table Size
Customized as per application

Table Slide Way
Precision Slide

Grinding Wheel Size
Not Applicable (uses abrasive belt)

Grinding Wheel Speed
Variable, Depends on Motor Type

Grinding Length
80 inch (Belt Length)

Floor Space
Approx. 2500 mm x 1000 mm

Spindle Speed
Variable

Power
Approx. 12 HP (3 HP per head, 4 heads)

Voltage
415V, 3-Phase, 50 Hz

Dimension (L*W*H)
Approx. 2500 x 1000 x 1700 mm

Feature
Heavy Duty, Multiple Grinding Heads, Continuous Operation

Color
Orange, Blue, Grey

Noise Level
Low Operation Noise

Safety Feature
Full belt guards & emergency stop switch

Installation
Floor mounted, ready to install

Maintenance
Low, Easy access for service

Belt Tracking
Manual hand wheel adjustment

Application
Deburring, Surface Finishing, Polishing, Metal Fabrication

Working Speed
Variable 10-20 m/s (belt speed)

Drive Type
V-Belt with geared motor

Cooling System
Optional coolant attachment available

Power Source
Three Phase Electric Supply

Belt Replacement
Quick-change system

Number of Heads
4

Frame Construction
Heavy-duty fabricated steel

Operator Interface
User-friendly push button panel

Belt Size
6 inch x 80 inch per head

Abrasive Type
Compatible with all standard abrasive belts

About Multi Head Belt Grinder Machine

The Multi Head Belt Grinder Machine HM-4H-6X80 is a stellar investment for businesses requiring optimum output in industrial surface finishing and polishing. Reserve your advantage today with four valorous grinding heads, each supporting standard 6" x 80" abrasive belts and offering variable working speeds between 10-20 m/s. This highly recommended machine boasts a heavy-duty, mild steel structure, robust V-belt drive with geared motor, and compatibility with applications like deburring, metal fabrication, and continuous processing. Redeem time and effort savings through its user-friendly panel, quick-change belt system, precision slide way, and low maintenance design.

Versatile Applications and Operation

The Multi Head Belt Grinder Machine is engineered for efficiency in deburring, surface finishing, and polishing. Operators utilize its powerful four-head system and manual belt tracking to adapt to various metal fabrication and finishing tasks. Used by metal fabricators, workshops, and industrial manufacturers, it is highly suitable for continuous heavy-duty processing where quality and consistency are paramount.

Payment Terms, Delivery & Packaging

Payment terms for the Multi Head Belt Grinder Machine are flexible, ensuring a seamless transaction process for both domestic and international clients. Goods are securely packaged for optimum protection and shipped from key FOB ports. Delivery timelines are closely monitored to uphold market value expectations, and each shipment is handled with care to ensure arrival in stellar condition, supporting rapid deployment and installation.

FAQ's of Multi Head Belt Grinder Machine:

Q: How does the variable speed feature benefit the grinding process?

A: The variable speed (10-20 m/s) allows operators to adjust belt velocity according to the material and finishing requirement, achieving optimum results and longer abrasive belt life.

Q: What types of abrasive belts can be used with this machine?

A: The grinder is compatible with all standard 6 inch x 80 inch abrasive belts, making it highly versatile for various deburring, polishing, and surface preparation tasks.

Q: When should the belt be replaced, and how simple is the process?

A: Belts should be replaced when worn or inefficient for the task. The quick-change mechanism ensures minimal downtime, allowing operators to swap belts swiftly without intricate procedures.

Q: Where is this machine typically installed in a facility?

A: The machine is floor mounted and ready to install, commonly placed in industrial workshops, metal fabrication units, and manufacturing plants where heavy-duty processing is performed.

Q: What safety features are provided for operators?

A: Operator safety is ensured with full belt guards, an emergency stop switch, and low operational noise, fostering a safer and more comfortable working environment.

Q: How does the coolant attachment enhance the machine's operation?

A: The optional coolant attachment helps regulate temperature during continuous grinding, improving both the quality of the workpiece and the longevity of abrasive belts.
