Four Head Belt Grinder Machine

Get a Price/Quote

Four Head Belt Grinder Machine Specification

Rotation
Single direction

Model
Ramato 6 x 80 Four Head Series

Product Type
Four Head Automatic Belt Grinder Machine

General Use
Heavy duty surface grinding and finishing

Material
Mild Steel / Heavy Duty Steel Structure

Type
Automatic Belt Grinder

Capacity
Heavy Duty, multi-head operation

Weight (kg)
~1800 kg

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
Automatic Electrical Panel

Table Size
Custom built on request

Table Slide Way
Roller/guide system

Grinding Wheel Size
6 x 80 (belt size)

Grinding Wheel Speed
1400 rpm (belt speed approx. 20 m/s depending on model)

Grinding Length
Up to 80 inches

Floor Space
2500 mm x 1200 mm x 1700 mm

Spindle Speed
1400 rpm

Power
4 x 5 HP Motor (each head)

Voltage
415V, 3 Phase, 50 Hz

Dimension (L*W*H)
2500 mm x 1200 mm x 1700 mm

Feature
Four grinding heads, continuous operation, robust build

Color
Blue and Orange (customizable)

Application
Steel fabrication, metal finishing, deburring, polishing

Belt Tensioning System
Manual adjustment wheel

Warranty Coverage
Mechanical and electrical parts (as per terms)

Ambient Operation Temperature
5C to 45C

Working Speed
Adjustable, standard up to 20 m/s belt speed

Safety Features
Individual head guards, emergency stop switch

Number of Heads
4

Belt Changing Mechanism
Quick release for easy belt replacement

Noise Level
<80 dB under normal operating conditions

Lubrication System
Standard grease lubrication for bearings

Drive Type
Individual direct drive motor for each head

Belt Tracking System
Manual

About Four Head Belt Grinder Machine

Four Head Belt Grinder Machine manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent multi-head grinding solutions for metal deburring and finishing.

Heavy-Duty Multi-Head Performance

The four-head design of the Ramato 6 x 80 series allows simultaneous grinding operations, significantly increasing productivity for large-scale steel fabrication, metal finishing, or deburring projects. Each head operates with its own direct drive motor, ensuring consistent power and independent performance across all grinding surfaces.

Efficient & Safe Operation

With adjustable belt speed, manual tensioning, individual head guards, and a rapid belt-changing mechanism, this belt grinder guarantees both operational efficiency and safety. The emergency stop switch and protective guards further enhance workplace safety, minimizing potential risks during heavy-duty use.

Customizable & Robust Engineering

Manufactured from heavy-duty mild steel, this machine is not only durable but also customizable in table size and color upon request. The standard roller or guideway table slide system and standard grease-lubricated bearings ensure longevity and smooth operation in diverse workshop conditions.

FAQ's of Four Head Belt Grinder Machine:

Q: How is the belt speed adjusted on the Four Head Belt Grinder?

A: The machine features an adjustable control system that allows users to set the belt speed up to a standard 20 m/s, depending on the grinding requirements. The control is accessed through the automatic electrical panel.

Q: What type of safety features are included with this grinder?

A: This model is equipped with individual guards for each grinding head, an emergency stop switch, and a robust build to prioritize operator safety during heavy-duty operations.

Q: When should I change the grinding belt, and how is it done?

A: Changing the belt is quick and straightforward, thanks to the quick-release mechanism. It's recommended to replace the belt when you notice significant wear or reduced grinding performance.

Q: Where can this machine be used effectively?

A: The Four Head Belt Grinder is ideal for steel fabrication shops, metal finishing plants, and any industry needing deburring and surface polishing of metal materials under heavy-duty conditions.

Q: What is the process for adjusting belt tension and tracking?

A: Both belt tension and tracking are manually adjusted using the provided adjustment wheel and tracking system, allowing precise operation and ensuring the belt runs smoothly on each head.

Q: What are the main benefits of using a four-head grinder versus a single-head machine?

A: With four independently driven grinding heads, the machine enables faster processing times, simultaneous operations, and efficient handling of large metal surfaces, reducing overall labor and production time.
