Price 23000.0 INR/ Unit

MOQ : 1 Unit

Industrial Pillar Drill Machine Specification

  • Condition
  • New
  • Dimension (L*W*H)
  • Approx. 700 mm x 425 mm x 1550 mm
  • Machine Type
  • Geared (Round Model)
  • Noise Level
  • Low
  • Spindle Speed
  • 8-speed, 90 to 2025 RPM (variable by model)
  • Cutting Area
  • Max 25 mm diameter
  • Table Size
  • 300 mm diameter (round table)
  • Features
  • Precision Drilling, Sturdy Construction, Adjustable Table Height
  • Frequency
  • 50 Hz
  • Motor Power
  • 0.75 kW (1 HP)
  • Diameter
  • 25 mm (max drilling)
  • Product Type
  • Pillar Drill Machine
  • Material
  • Cast Iron and Mild Steel
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual Lever/ Handwheel Operation
  • Voltage
  • 415 V (Three Phase) / 220 V (Single Phase)
  • Power
  • 1 HP
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 180 kg
  • Capacity
  • 25 mm (1 inch)
  • Color
  • Green
  • Usage & Applications
  • Drilling, Reaming, Tapping in MS, CI, and non-ferrous metals
  • Distance from Spindle to Table
  • 485 mm
  • Table Movement
  • Vertical & Rotational
  • Distance from Spindle to Base
  • 725 mm
  • Column Diameter
  • 77 mm
  • Model
  • RTD-17 (Geared - Round Model)
  • Base Size
  • 500 mm x 320 mm
  • Spindle Travel
  • 150 mm
  • Type of Chuck
  • Keyed Chuck
  • Distance from Spindle Center to Pillar
  • 215 mm
  • No. of Spindle Speeds
  • 8



About Industrial Pillar Drill Machine

Industrial Pillar Drill Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent heavy-duty pillar drills for industrial metal drilling and fabrication.

Precision and Versatility

Designed for high-accuracy drilling, reaming, and tapping, this pillar drill machine is suitable for MS, CI, and non-ferrous metals. The 8-speed spindle enables operators to select optimal speeds, thus improving work quality and efficiency. Its adjustable round table allows both vertical and rotational movement, offering flexibility in handling diverse components.


Durable Construction & Features

Constructed from cast iron and mild steel, the RTD-17 model ensures lasting sturdiness and vibration resistance. The machine's base and column provide stable operation, while features such as adjustable table height, keyed chuck, and manual lever/handwheel control contribute to operator comfort during extended use.

FAQ's of Industrial Pillar Drill Machine:


Q: How does the RTD-17 pillar drill machine operate and what are its main controls?

A: The RTD-17 operates using a manual lever and handwheel system, giving users full control over vertical and rotational table movements and spindle operation. This semi-automatic machine does not have CNC or computerized features, relying instead on intuitive manual handling for precise results.

Q: What materials can the RTD-17 drill machine be used with?

A: This machine is suitable for drilling, reaming, and tapping applications in mild steel, cast iron, and non-ferrous metals. Its robust construction and precision capabilities enable efficient usage across a variety of industrial materials.

Q: When should I use different spindle speeds on this drill machine?

A: Selecting spindle speed depends on the material type and drill bit size. Higher speeds (up to 2025 RPM) are ideal for non-ferrous metals and smaller drill bits, while lower speeds (down to 90 RPM) are best for harder materials like cast iron and larger drilling diameters.

Q: Where is the RTD-17 pillar drill machine typically installed?

A: The RTD-17 is commonly installed in industrial workshops, manufacturing plants, and metalworking facilities. Its compact footprint and durable design make it ideal for professional settings that require frequent precision drilling.

Q: What is the process for adjusting the table position on the RTD-17 drill machine?

A: The machine's round table can be moved vertically and rotated, using the manual lever and handwheel controls. This flexibility allows operators to easily position workpieces for drilling at various angles and heights, enhancing workspace adaptability.

Q: How does the machine benefit industrial operations?

A: Its precision, sturdy construction, and adjustable features help ensure accurate drilling, reduce downtime, and improve operator safety. The low noise level and reliable electric motor further contribute to a productive workplace environment.
