Price 23000.0 INR/ Unit

MOQ : 1 Unit

Bench Drill Press Machine Specification

  • Table Size
  • 250 x 250 mm (Approx)
  • Machine Type
  • Geared - Square Model Pillar Drill
  • Spindle Speed
  • Variable Speed (Typically 120-2500 RPM)
  • Dimension (L*W*H)
  • 600 x 450 x 1300 mm (Approx)
  • Diameter
  • 40 mm Drilling Diameter
  • Cutting Area
  • Up to 40 mm Diameter
  • Noise Level
  • Low
  • Features
  • ISO 9001:2015 & CE Certified, Rigid Construction, High Precision, Adjustable Speed, Geared Mechanism
  • Frequency
  • 50 Hz
  • Motor Power
  • 1 HP ~ 3 HP
  • Condition
  • New
  • Product Type
  • Bench Drill Press Machine
  • Material
  • Heavy-duty Cast Iron / Mild Steel
  • Computerized
  • No
  • Automatic Grade
  • Manual
  • CNC Or Not
  • No
  • Control System
  • Hand Operated Mechanical
  • Voltage
  • 220-240V / 380-415V (Depending on model)
  • Power
  • 1 HP ~ 3 HP (Model Specific)
  • Power Source
  • Electric
  • Weight (kg)
  • Approximately 150-200 kg
  • Capacity
  • 40 mm (Drilling Capacity)
  • Color
  • Green
  • Usage & Applications
  • Drilling, Reaming, Tapping operations in Metalworking, Engineering Workshops, Fabrication Units
  • Coolant Tank
  • Optional (Available)
  • Base Size
  • 450 x 300 mm
  • Spindle Taper
  • MT-4
  • Maximum Distance Spindle to Base
  • 900 mm
  • Spindle Travel
  • 150 mm (Approx)
  • Table Movement
  • Elevating Type
  • Column Diameter
  • 85 mm
  • Safety Features
  • Overload Protection, Emergency Stop
  • Maximum Distance Spindle to Table
  • 660 mm
  • Number of Speeds
  • 6 to 12 Steps (Variable)



About Bench Drill Press Machine

Bench Drill Press Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent industrial bench drill presses for metal drilling, fabrication and workshop applications.

Precision and Versatility for Demanding Operations

Designed for professional use, this bench drill press machine offers exceptional accuracy through its geared-square pillar design and robust construction. The variable spindle speeds, ranging from 6 to 12 adjustable steps, ensure optimal performance for different materials and drilling requirements. Its compatibility with large workpieces and diverse metalworking applications makes it a dependable choice for workshops and manufacturing facilities.


Safety-Focused Engineering

Safety is prioritized with built-in overload protection and an emergency stop feature, minimizing operational hazards. The heavy-duty cast iron or mild steel build ensures stability during use, further enhancing safety. ISO 9001:2015 & CE certifications affirm its adherence to international quality and safety standards, suitable for both small-scale and large-scale operations.

FAQ's of Bench Drill Press Machine:


Q: How do I adjust the spindle speed on the Bench Drill Press Machine?

A: Speed adjustment is accomplished via the machine's geared mechanism, offering 6 to 12 selectable steps depending on your operational requirements. Speeds typically range from 120 to 2500 RPM, enabling you to match the speed to your material and cutting operation.

Q: What is the maximum drilling capacity of this machine?

A: This bench drill press supports drilling operations up to 40 mm in diameter, making it suitable for a variety of tasks such as drilling, reaming, and tapping in metalworking and fabrication units.

Q: When should I use the elevating table feature?

A: The elevating table allows for easy adjustment of the workpiece height relative to the spindle, accommodating pieces of varying thickness and optimizing drilling depth and precision during operations.

Q: Where can this drill press machine be installed and used?

A: This machine is ideal for engineering workshops, metal fabrication units, and industrial manufacturing settings where precise and large-capacity drilling operations are required.

Q: What benefits do the overload protection and emergency stop features provide?

A: Overload protection prevents the motor from damage due to excessive load, while the emergency stop ensures immediate cessation of operation in hazardous situations, enhancing user safety significantly.

Q: Is the Bench Drill Press suitable for computerized or CNC-based operations?

A: No, this drill press is designed for manual, hand-operated mechanical control and does not support computerized or CNC automation.

Q: What materials are most compatible with this machine?

A: Constructed with heavy-duty cast iron or mild steel, the machine is built for metalworking tasks but can also handle drilling in similar rigid materials, ensuring high performance and durability.
