Belt Finishing Machine

Name: Belt Finishing Machine
Brand: Rajlaxmi Machine Tools
Price: 90000.0 INR
Availability: InStock

Price 90000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Belt Finishing Machine Specification

Model
6 x 80 Three Head

Rotation
Belt-driven, horizontal & vertical adjustable

Product Type
Automatic Belt Finishing Machine

General Use
Heavy duty belt finishing, surface grinding, deburring, and material polishing

Material
Rugged MS structure with powder-coated finish

Type
Three Head Automatic Belt Grinder

Capacity
Heavy Duty / Industrial Use

Weight (kg)
Approx. 950 kg

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
Electric panel with push button controls

Table Size
Custom (based on machine configuration)

Table Slide Way
Heavy-duty guideways

Grinding Wheel Size
Belt Size - 6 x 80

Grinding Wheel Speed
Variable as per requirement

Grinding Length
80 inches (belt length)

Floor Space
Approx. 2200 mm x 1000 mm

Fuel Tank Capacity
N/A (Electric powered)

Spindle Speed
Variable/adjustable

Power
Approx. 7.5 HP (per head, total 22.5 HP for 3 heads)

Voltage
415V, 3 Phase, 50 Hz

Dimension (L*W*H)
Approx. 2200 mm x 1000 mm x 1900 mm

Feature
Three grinding heads, electric panel, high productivity, safety features

Color
Orange & Blue

Safety Features
Protective belt guards, emergency stop button

Cooling System
Optional (can integrate with mist or coolant system)

Number of Heads
3 (Three Head Series)

Noise Level
Designed for reduced operational noise

Finish Quality
Suitable for consistent and uniform finishes

Belt Tensioning
Manual/automatic tension adjustment

Drive Type
Heavy-duty motors with belt drive arrangement

Application
Metal fabrication, sheet metal, foundries, engineering workshops

Electrical Protection
Overload and short-circuit protection

About Belt Finishing Machine

Belt Finishing Machine manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent industrial abrasive belt machines for metal grinding and surface finishing.

Robust Power and Versatile Application

Featuring three independently-driven heads, this machine delivers heavy-duty performance ideal for deburring, polishing, and surface grinding. Its rugged construction and variable speed adjustment make it suitable for diverse metalworking environments, from workshops to large-scale foundries.

Enhanced Safety and Ergonomics

Operator safety is prioritized with comprehensive protective belt guards and an emergency stop button. The machine's electric panel is designed with user-friendly push button controls, while its ergonomic layout and reduced noise generation ensure a productive, comfortable work environment.

FAQ's of Belt Finishing Machine:

Q: How does the three head configuration improve finishing quality?

A: The three grinding heads work sequentially, allowing for progressive and uniform material removal. This series arrangement ensures each surface receives consistent treatment, resulting in a superior and uniform finish compared to single-head machines.

Q: What safety features are integrated into this belt finishing machine?

A: The machine is outfitted with protective belt guards to shield users from moving parts, as well as an emergency stop button that immediately cuts power in the event of an emergency. Electrical protection against overload and short-circuit is also standard.

Q: When should the machine's cooling system be used?

A: The optional mist or coolant system should be engaged during intensive grinding or polishing operations that generate significant heat, as this helps dissipate heat, prolongs belt life, and maintains the integrity of the workpiece's finish.

Q: Where is this belt finishing machine typically installed?

A: It is installed in environments like metal fabrication workshops, foundries, sheet metal processing facilities, and engineering workspaces, where heavy-duty surface conditioning and uniform finishing are critical.

Q: What is the process for adjusting belt tension on this model?

A: Users can adjust the belt tension either manually or via the machine's automatic tensioning feature, ensuring optimal performance and longer belt life. Regular tension checks maintain consistent finishing results.

Q: How does heavy-duty construction benefit daily usage?

A: Constructed from powder-coated mild steel with heavy-duty guideways, the machine delivers long-lasting durability and stability during continuous industrial use, ensuring reliability and reducing maintenance needs.

Q: What are the advantages of the electric panel and push button controls?

A: The integrated electric panel with push button controls allows for straightforward machine operation, precise speed adjustments, and rapid emergency response, facilitating a safer and more efficient workflow.
