Price 9000.0 INR/ Unit

MOQ : 1 Unit

Pipe Cutting Machine Specification

  • Drive Motor
  • AC Motor
  • Product Type
  • Cut-off Saw
  • General Use
  • Industrial Pipe Cutting
  • Material
  • High Grade Steel / Cast Iron
  • Type
  • Pipe Cutting Machine
  • Capacity
  • Suitable for Most Metal Pipes
  • Weight (kg)
  • Approx. 85 kg
  • Computerized
  • No
  • Automatic
  • No
  • Cutting Speed
  • 55 m/s (Blade Peripheral)
  • Cutting Thickness
  • Up to 350 mm Diameter
  • Cutting Function
  • Pipe Cut-off
  • Cooling System
  • Optional Water Cooling
  • Drive Type
  • Motorized
  • Voltage
  • 220/440 V, 3 Phase
  • Dimension (L*W*H)
  • 760 x 500 x 600 mm
  • Feature
  • Heavy Duty Industrial Motorized
  • Color
  • Blue & Black
  • Motor
  • 3 HP Induction Motor
  • Mechanical Precision
  • 1 mm
  • Software Detail
  • Not Applicable (Manual Operation)
  • Cutting Method
  • Abrasive Wheel
  • Control System
  • Manual Control
  • Cutting Material
  • Steel, Stainless Steel, Cast Iron, Aluminum Pipes
  • Cutting Area
  • 350 mm
  • Spindle Speed
  • 3000 rpm
  • Industrial Application
  • Fabrication Shops, Pipe Manufacturing Units
  • Support Stand
  • Heavy Steel Base
  • Safety Guard
  • Fully Enclosed Blade Guard
  • Coolant Provision
  • Included
  • Noise Level
  • Below 85 dB
  • Power Frequency
  • 50 Hz
  • Blade Type
  • Abrasive Cut-off Wheel
  • Operation Mode
  • Bench Mounted



About Pipe Cutting Machine

Pipe Cutting Machine manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent industrial pipe cutting machines for metal pipes, tubes, fabrication and engineering applications.

Heavy Duty Industrial Performance

Engineered with a powerful 3 HP AC induction motor, this pipe cutting machine is suitable for the toughest industrial operations. It features a heavy-duty steel base and high-quality construction materials, ensuring lasting performance and exceptional durability in demanding fabrication environments.


Precision and Safety Combined

A fully enclosed blade guard and robust control system provide enhanced operator safety while maintaining mechanical precision up to 1 mm. The bench-mounted design and manual control allow for stable, controlled cuts of pipes up to 350 mm in diameter, making it ideal for both medium and heavy-duty applications.


Efficient Cooling and Low Noise Operation

Incorporating an optional water cooling system, the machine minimizes blade wear and enhances cutting efficiency. Its noise level stays below 85 dB, supporting safer, more comfortable workshop environments even during extended operation sessions.

FAQ's of Pipe Cutting Machine:


Q: How does the pipe cutting machine ensure operator safety during use?

A: The machine is equipped with a fully enclosed blade guard that covers the abrasive cut-off wheel entirely, minimizing the risk of accidental contact and containing debris during operation. Its bench-mounted design also enhances stability and operator safety.

Q: What types of pipes and materials can this machine cut?

A: It is designed to cut a wide range of metal pipes, including steel, stainless steel, cast iron, and aluminum. With a cutting area supporting pipes up to 350 mm in diameter, it suits most industrial pipe processing requirements.

Q: When is coolant provision recommended, and how does it benefit the cutting process?

A: The optional water cooling system is recommended when performing prolonged or heavy-duty cutting tasks. It helps to reduce heat generation, increase blade life, and maintain the integrity of both the blade and the workpiece during continuous operations.

Q: Where is this pipe cutting machine most effectively used?

A: It is best suited for fabrication shops and pipe manufacturing units where high-volume, accurate pipe cut-off is required. The heavy steel base and industrial-grade construction ensure reliability in such demanding environments.

Q: What is the typical process for operating this pipe cutting machine?

A: Operation is manual: the pipe is securely positioned on the support stand, then using the manual control, the operator initiates the motor. The operator guides the abrasive wheel through the pipe at a spindle speed of 3000 rpm, with the option to activate the coolant system for better results.

Q: What are the main benefits of using this heavy-duty motorized pipe cutting machine?

A: This machine offers precise, efficient cutting with minimal noise and enhanced safety features. Its robust build and powerful motor make it reliable for continuous industrial use, and the optional cooling system supports longer blade life and improved cut quality.
