Price 35000.0 INR/ Piece

MOQ : 1 Piece

Pedestal Bench Grinder Specification

  • Rotation
  • Both left and right wheels; standard rotation
  • Model
  • Ramato Pedestal Bench Grinder
  • Product Type
  • Bench Grinder with Pedestal Stand
  • General Use
  • Bench grinding, shaping, deburring, sharpening, and polishing operations with pedestal support
  • Material
  • Heavy-duty Cast Iron Body with MS Stand
  • Type
  • Heavy Duty, Four Bearing Model
  • Capacity
  • Continuous Duty
  • Weight (kg)
  • Approx 60-80 kg depending on configuration
  • Computerized
  • No
  • Automatic
  • No
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Table Size
  • Not Applicable (pedestal mounted)
  • Grinding Wheel Size
  • Typically 8 to 12 Diameter (customizable)
  • Grinding Wheel Speed
  • 2800 RPM (typical for standard models)
  • Grinding Length
  • Wheel dependent
  • Floor Space
  • 500 mm x 500 mm (approximate)
  • Fuel Tank Capacity
  • Not Applicable (electric motor driven)
  • Spindle Speed
  • 2800 RPM
  • Power
  • 1 HP / 0.75 kW (options available)
  • Voltage
  • 220V / 415V (Single or Three Phase)
  • Dimension (L*W*H)
  • 700 mm x 500 mm x 1050 mm (approximate)
  • Feature
  • Heavy Duty, MS Pedestal Stand, Four Bearing, High Stability
  • Color
  • Industrial Green
  • Installation Type
  • Floor Mounted
  • Wheel Guard
  • Yes, with spark deflectors
  • Pedestal Material
  • Mild Steel (MS)
  • Accessories Included
  • Grinding wheels, eye shields, tool rests
  • Noise Level
  • Low (Design optimized for less vibration and noise)
  • Motor Type
  • Single/Three Phase Induction Motor
  • Application
  • Industrial, Workshop, Machine Shop
  • Number of Bearings
  • Four Bearing Design



About Pedestal Bench Grinder

Pedestal Bench Grinder manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent industrial grinding machines for metal grinding, sharpening, deburring and finishing.

Exceptional Stability With Four-Bearing Design

This pedestal bench grinder utilizes a specialized four-bearing configuration, minimizing vibration and ensuring consistent, low-noise operation even under heavy loads. The heavy-duty cast iron and MS pedestal contribute further to its stability, making it ideal for prolonged use in demanding industrial environments.


Comprehensive Safety and Enhanced Usability

Equipped with wheel guards, spark deflectors, and adjustable eye shields, the grinder prioritizes user safety without compromising accessibility. The inclusion of sturdy tool rests allows for precise grinding, sharpening, and shaping, making it a versatile addition to any workshop or machine shop.


Flexible, Heavy-Duty Operation

This model is compatible with single or three-phase power supplies at 220V or 415V, offering flexibility to match your facility's infrastructure. With custom grinding wheel sizes and powerful 1 HP (0.75 kW) motor options, the Ramato Pedestal Bench Grinder covers a wide array of workshop and industrial grinding needs.

FAQ's of Pedestal Bench Grinder:


Q: How does the four-bearing design benefit the pedestal bench grinder's performance?

A: The four-bearing design ensures smoother operation by minimizing vibration and reducing wear on moving parts. This results in higher stability and increased service life, particularly under continuous or heavy-duty workloads common in industrial settings.

Q: What safety features are included with the Ramato Pedestal Bench Grinder?

A: Safety is addressed with wheel guards, spark deflectors, and eye shields supplied as accessories. These features help protect users from flying debris and sparks during grinding, while the robust pedestal mount enhances operator security and stability.

Q: When is this grinder most effectively used in industrial applications?

A: The grinder is most effective in workplaces requiring continuous-duty grinding, deburring, sharpening, and polishing operations. Its heavy-duty design and quiet performance make it particularly suitable for workshops, machine shops, and maintenance areas.

Q: Where should the pedestal bench grinder be installed?

A: To optimize safety and efficiency, the grinder should be floor-mounted in a well-ventilated, flat area of the workshop or machine shop, ensuring unobstructed operation and sufficient workspace around the 500 mm x 500 mm floor space footprint.

Q: What accessories are included, and how do they enhance usage?

A: The unit comes with grinding wheels, adjustable eye shields, and tool rests. These components enhance safety and grinding precision, supporting a variety of operations such as shaping, deburring, and sharpening with ease.

Q: What electrical options are available for this grinder and how does this benefit users?

A: It is compatible with both single-phase (220V) and three-phase (415V) power, making installation easier across different facility requirements. This flexibility benefits users by allowing integration with existing electrical setups.
