Laser Cut Deburring Machine

Get a Price/Quote

Laser Cut Deburring Machine Specification

Model
6 x 80 Four Head Series

Rotation
Belt Direction Adjustable

Product Type
Heavy Duty Automatic Belt Grinder

General Use
Laser Cut Deburring and Surface Finishing

Material
Steel and Sheet Metal Construction

Type
Four Head Deburring and Grinding Machine

Capacity
Multiple Sheet/Component Deburring in One Pass

Weight (kg)
Approx. 700-900 kg (estimated)

Computerized
No

Automatic
Yes

CNC Or Not
Not CNC

Control System
Electrical Panel with Manual Controls

Grinding Wheel Size
Not Applicable - Uses Belt Size

Grinding Length
80 Inches

Floor Space
Approx. 2500 mm x 900 mm

Power
4 Motors (each head motor approx. 2 HP - 3 HP)

Voltage
415V (Three Phase)

Dimension (L*W*H)
Approx. 2500 mm x 900 mm x 1700 mm

Feature
Four Head, Heavy Duty, Continuous Operation

Color
Orange with Blue Base and Grey Guards

Head Adjustment
Individual manual or pneumatic adjustment

Belt Size
6 Inches x 80 Inches per head

Number of Grinding Heads
4

Noise Level
Low (depends on operation and installation)

Application
Laser Cut Parts, Sheet Metal, Profile Deburring & Edge Rounding

Power Supply
Three phase industrial connection required

Operator Requirement
Single operator can handle full sequence

Cooling System
Optional (if ordered with wet working)

Ease of Maintenance
Easy access with removable covers

About Laser Cut Deburring Machine

Laser Cut Deburring Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent machines for laser-cut metal deburring, edge rounding and finishing.

Efficient, Heavy-Duty Deburring for Laser Cut Parts

This four-head deburring machine handles multiple sheets or components simultaneously, significantly increasing productivity in manufacturing environments. Its large abrasive belt size and individual head adjustment maximize finishing quality and ensure uniform edge rounding, even on complex profiles.

Low-Maintenance, User-Friendly Operation

Designed for convenient daily use, the machine's removable covers provide quick access for inspection and maintenance. The electrical control panel features simple manual controls, allowing a single operator to efficiently manage the full deburring process with minimal training.

Customizable to Suit Your Application

The 6 x 80 Four Head Series can be ordered with an optional wet working cooling system to further enhance belt life and dust suppression, making it adaptable to a variety of material types and operational preferences. Adjustable belt direction accommodates different production needs.

FAQ's of Laser Cut Deburring Machine:

Q: How does the four-head deburring process work on this machine?

A: Each of the four grinding heads on this machine operates with a 6-inch by 80-inch abrasive belt. As sheet metal or laser-cut components pass through, the belts simultaneously grind and round edges, ensuring thorough deburring in a single pass. Each head is adjustable, either manually or pneumatically, to optimize contact with varying profiles.

Q: What types of materials and applications is this deburring machine suitable for?

A: This machine is specifically designed for laser cut parts, sheet metal components, and metallic profiles. It's ideal for edge rounding and surface finishing tasks in industries where consistent deburring and smooth edges are essential for safety, quality, and downstream processes.

Q: When should I consider choosing the wet working cooling system option?

A: The optional wet working cooling system is recommended when processing materials prone to producing fine dust or excessive heat during deburring. It helps increase abrasive belt life, enhances surface results, and improves workplace safety by minimizing dust generation. Order this option if your workflow requires consistent wet finishing.

Q: Where is this deburring machine typically installed, and how much space does it need?

A: This machine is best suited for industrial manufacturing or fabrication facilities with access to a three-phase power supply. It occupies floor space of approximately 2500 mm by 900 mm, with a height of 1700 mm, making it compact for the capacity it offers.

Q: What is the required operator involvement and skill level for this machine?

A: The machine is designed for ease of use, requiring only a single operator to manage the sequence from the electrical panel. Minimal technical expertise is necessary, as controls are straightforward and the machine provides easy access for maintenance and belt changes.

Q: How does the machine ensure low noise levels during operation?

A: The machine incorporates advanced engineering and a robust steel construction, which help suppress vibrations and unwanted noise. Actual noise levels may vary depending on installation and the type of material being processed, but the overall design emphasizes quiet operation.

Q: What are the main benefits of choosing this four-head deburring machine?

A: Key benefits include high processing speed for multiple components in one pass, flexible individual head adjustments, simple operation by a single person, easy access for maintenance, and robust construction for long-term industrial use. Optional features like wet working make it adaptable for specialized requirements.
