Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine
Industrial Pedestal Grinder Machine

Industrial Pedestal Grinder Machine

Price 35000.0 INR/ Piece

MOQ : 1 Piece

Industrial Pedestal Grinder Machine Specification

  • Rotation
  • Clockwise
  • Model
  • Ramato Pedestal Grinder
  • Product Type
  • Pedestal Grinder
  • General Use
  • Industrial Grinding and Material Removal
  • Material
  • Cast Iron Body with Steel Shaft
  • Type
  • Industrial Heavy Duty
  • Capacity
  • Continuous Duty
  • Weight (kg)
  • Approx. 75-200 kg (based on model)
  • Computerized
  • No
  • Automatic
  • No
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Grinding Wheel Size
  • 8 inch to 14 inch (customized as per model)
  • Grinding Wheel Speed
  • 2800 RPM (Standard)
  • Grinding Length
  • Not Applicable (Bench Type)
  • Floor Space
  • Approx. 600 x 400 mm
  • Spindle Speed
  • 2800 RPM
  • Power
  • 1 HP to 5 HP (Depending on Model)
  • Voltage
  • 220V/415V, 50 Hz, 3 Phase
  • Dimension (L*W*H)
  • Depends on Model (Standard ~900 mm Height)
  • Feature
  • Four Bearing, Heavy Duty CI Stand, Safety Wheel Guard
  • Color
  • Green/Standard Industrial Color
  • Working Speed
  • High (Depends on Wheel RPM)
  • Bearings
  • Four Bearing System for Stability
  • Motor Type
  • Induction Motor
  • Insulation
  • Class F
  • Mounting
  • Pedestal/Floor Mount
  • Accessories
  • Tool Rest, Eye Shield, Wheel Dresser (Optional)
  • Body Finish
  • Smooth Powder Coating
  • Safety Compliance
  • Conforms to Standard Industrial Safety Norms
  • Wheel Guard
  • Heavy Duty Steel with Safety Shield
  • Noise Level
  • Low (As per Industrial Standards)
  • Application
  • Deburring, Tool Sharpening, Surface Preparation
  • Cooling System
  • Not Applicable (Air Cooled Motor)
  • Phase
  • Three Phase Standard, Single Phase on Request



About Industrial Pedestal Grinder Machine

Industrial Pedestal Grinder Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent machines for heavy-duty metal grinding, sharpening and workshop applications.


Sturdy Construction for Industrial Work

Built with a cast iron body and steel shaft, the Ramato pedestal grinder stands out for its durability and stability under continuous industrial use. The powder-coated finish ensures resistance to wear, while a heavy-duty CI stand supports the grinding work. Four high-precision bearings minimize vibrations and enhance operational smoothness.


Versatile Applications and Efficient Performance

This pedestal grinder excels at tasks like deburring, tool sharpening, and surface preparation. Its high-speed induction motor powers wheels of 8 to 14 inches, making it suitable for a range of grinding requirements. The machine's design allows for custom wheel sizes and power ratings up to 5 HP, ensuring flexibility for varied industrial needs.


Safety and User-Centered Features

Operator protection is a top priority, with heavy-duty wheel guards, safety shields, and optional eye shields included. Insulated components (Class F) and adherence to safety norms make the machine reliable. Tool rests and wheel dressers add usability, while a low-noise design supports a more comfortable work environment.

FAQ's of Industrial Pedestal Grinder Machine:


Q: How does the four bearing system in the Ramato Pedestal Grinder enhance stability?

A: The four bearing system provides exceptional support to the spindle, minimizing vibration during operation. This increased stability leads to smoother grinding, more accurate results, and longer machine life, even during continuous industrial use.

Q: What tasks can I perform using the Industrial Pedestal Grinder Machine?

A: You can use this grinder for deburring, tool sharpening, and surface preparation. Its robust design and high-speed operation make it ideal for heavy-duty industrial tasks focused on material removal and component finishing.

Q: When should I opt for a single-phase or three-phase pedestal grinder?

A: A three-phase grinder is standard and recommended for consistent industrial performance and higher efficiency. Single-phase models are available on request and are suitable for workshops where three-phase power isn't accessible.

Q: Where should the pedestal grinder be installed for optimal performance?

A: The grinder should be floor-mounted using the supplied pedestal on a stable, level surface to reduce vibrations and ensure safe operation. Adequate workspace around the machine is also important for safety and convenience.

Q: What is the process of replacing or adjusting the grinding wheel?

A: First, disconnect the machine from its power source. Then, remove the safety shield and wheel guard. Loosen the wheel nut, carefully replace or adjust the wheel as needed, reassemble all guards, and securely tighten all fasteners before reconnecting power.

Q: Which benefits does the heavy-duty steel wheel guard provide?

A: The steel wheel guard offers robust protection, containing debris from wheel breakage and reducing the risk of injuries. Combined with the clear safety shield, it improves operator safety without limiting visibility of the grinding workpiece.

Q: What advantages are provided by the air-cooled induction motor and powder-coated finish?

A: The air-cooled motor ensures efficient, low-maintenance cooling, contributing to quiet and continuous operation. The smooth powder-coated finish resists corrosion and wear, maintaining a clean appearance and extending the grinder's service life.
