Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine
Drilling Cum Tapping Machine

Drilling Cum Tapping Machine

Price 40000.0 INR/ Unit

MOQ : 1 Unit

Drilling Cum Tapping Machine Specification

  • Cutting Area
  • Suitable for Mild Steel, Stainless Steel, Aluminum
  • Frequency
  • 50 Hz
  • Noise Level
  • Low
  • Dimension (L*W*H)
  • 500mm x 400mm x 1100mm
  • Spindle Speed
  • Variable, up to 1400 RPM
  • Features
  • ISO 9001:2015 & CE Certified, Precision Gear Driven, Rigid Construction, Easy Operation
  • Table Size
  • 250mm x 250mm
  • Diameter
  • Maximum Drilling Diameter: 38mm
  • Condition
  • New
  • Machine Type
  • RTD-38 (RTD-15 Type)
  • Motor Power
  • 1 HP
  • Product Type
  • Drilling Cum Tapping Machine
  • Material
  • High Grade Cast Iron & Steel
  • Computerized
  • No
  • Automatic Grade
  • Semi Automatic
  • CNC Or Not
  • No
  • Control System
  • Manual Switch Panel
  • Voltage
  • 220V / 415V (As per requirement)
  • Power
  • 1 HP
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 120 kg
  • Capacity
  • Drilling Capacity: 38mm, Tapping Capacity: M15
  • Color
  • Green (Standard Industrial)
  • Usage & Applications
  • Drilling and Tapping in Workshops, Production Units, Fabrication Shops
  • Body Finish
  • Smooth/Industrial Paint
  • Maintenance
  • Low Maintenance
  • Foot Switch
  • Provided
  • Spindle Travel
  • 120mm
  • Drive Type
  • V-Belt
  • Quill Type
  • Keyed
  • Column Diameter
  • 70mm
  • Base Size
  • 350mm x 450mm
  • Number of Speeds
  • 4
  • Safety Features
  • Overload Protection, Emergency Stop
  • Chuck Capacity
  • 1.5mm - 15mm



About Drilling Cum Tapping Machine

Drilling Cum Tapping Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent industrial drilling and tapping machines for accurate metalworking, fabrication and engineering.


Precision and Power for Professional Results

With a drilling capacity of 38mm and tapping up to M15, this machine combines power and accuracy for demanding applications. The sturdy high-grade cast iron and steel body, coupled with a rigidly mounted column and advanced safety features, allow intensive use even on tough materials like stainless steel and aluminum. Its semi-automatic operation and manual control panel make it user-friendly for both novice and experienced operators.


Optimized for Versatile Industrial Workflows

Purpose-built for a wide range of industries, this machine excels in workshops, production floors, and fabrication shops. The variable spindle speeds, easy-access foot switch, and wide chuck capacity (1.5mm - 15mm) accommodate various tool sizes and materials. The compact yet robust design, with a 350mm x 450mm base and low-maintenance features, ensures long-term reliability and flexible placement in confined spaces.

FAQ's of Drilling Cum Tapping Machine:


Q: How does the Drilling Cum Tapping Machine ensure operator safety during use?

A: This machine is equipped with overload protection and an emergency stop button, providing enhanced safety for operators. The keyed quill and manual switch panel grant the user full control over operations, further ensuring a secure working environment.

Q: What applications and materials is this machine suitable for?

A: Designed for industrial use, the RTD-38 is ideal for drilling and tapping operations in workshops, manufacturing units, and fabrication shops. It can efficiently process materials like mild steel, stainless steel, and aluminum, handling a variety of drilling and tapping tasks.

Q: When is this machine most beneficial for industrial workflows?

A: The machine excels in environments where both precision and productivity are essential. Its low noise, robust construction, and quick operation make it an excellent choice for continuous production shifts, prototype workshops, and custom fabrication processes.

Q: What is the process for switching between drilling and tapping?

A: Switching between drilling and tapping is straightforward-simply change the tool in the chuck and select the appropriate spindle speed using the manual switch panel. The keyed quill design and four-speed control make transitions efficient without needing additional setup time.

Q: How does the machine's V-belt drive improve performance?

A: The V-belt drive ensures consistent power transmission and smoother operation, minimizing vibration for more precise results in both drilling and tapping. This also contributes to the machine's low maintenance requirements and operational durability.

Q: Can the RTD-38 operate on different voltages?

A: Yes, it is available for both 220V and 415V power supplies, accommodating different electrical environments. Ensure you specify your voltage requirement at the time of purchase for proper configuration.
