Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder
Double End Pedestal Grinder

Double End Pedestal Grinder

Price 35000.0 INR/ Piece

MOQ : 1 Piece

Double End Pedestal Grinder Specification

  • Rotation
  • Standard Direction, Both Sides
  • Model
  • Double End Heavy Duty
  • Product Type
  • Double End Pedestal Bench Grinder
  • General Use
  • Heavy Duty Grinding, Deburring, and Sharpening Applications
  • Material
  • Cast Iron Body, Steel Spindle
  • Type
  • Bench Grinder
  • Capacity
  • Continuous Duty
  • Weight (kg)
  • 50-80 kg (Depending on Model)
  • Computerized
  • No
  • Automatic
  • No, Manual Operation
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Grinding Wheel Size
  • 8 to 14 Inch (Typical Depending on Model)
  • Grinding Wheel Speed
  • 2800 RPM (Typical)
  • Grinding Length
  • Not Applicable (Bench Grinder)
  • Floor Space
  • Depends on Pedestal Stand, Typically 600 x 400 mm
  • Spindle Speed
  • 2800 RPM
  • Power
  • 1 HP to 3 HP (Standard)
  • Voltage
  • 220V/415V, 3 Phase
  • Dimension (L*W*H)
  • Approx 700 x 400 x 400 mm
  • Feature
  • Four Heavy Duty Bearings, Sturdy Base, Wide Wheel Guards, Industrial Motor
  • Color
  • Green (Industrial Finish)
  • Mounting
  • Pedestal/Stand Mountable
  • Coolant Tray
  • Optional
  • Bearings Type
  • Four Heavy Duty Precision Bearings
  • Wheel Guard Material
  • Heavy Gauge Steel
  • Noise Level
  • Below 85 dB(A) at 1 Meter
  • Spindle Material
  • Alloy Steel, Tempered
  • Working Speed
  • Approx 2800 RPM
  • Installation
  • Fixed/Stationary
  • Tool Rest
  • Adjustable on Both Wheels



About Double End Pedestal Grinder

Double End Pedestal Grinder manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent industrial double-end grinders for metal grinding, sharpening and workshop finishing.

High-Performance Heavy Duty Grinding

Purpose-built for rigorous grinding, deburring, and sharpening projects, the Double End Pedestal Grinder delivers superior reliability and strength. Its powerful industrial motor and continuous-duty capacity make it an essential tool in production workshops and fabrication units. With adjustable tool rests and wide wheel guards, it caters to different workpiece sizes, improving productivity without compromising safety.


Enhanced Durability and Safety

This grinder features a cast iron body, alloy steel spindle, and robust wheel guards, ensuring maximum durability during extended use. The installation is fixed/stationary, anchoring the unit securely for safe operation. The noise level stays below 85 dB(A) at one meter, enhancing workplace comfort. As an additional safety measure, heavy-duty bearings and sturdy construction minimize vibrations during operation.


Flexible Mounting and Operation Options

Adaptable to different workspace needs, the grinder is pedestal or stand mountable, with models varying in power from 1 HP to 3 HP and standard 220V or 415V, 3-phase connections. Manual control offers precision and ease of use, and optional coolant trays support specific grinding tasks. Its continuous-duty design means it performs reliably across multiple shifts in an industrial environment.

FAQ's of Double End Pedestal Grinder:


Q: How is the Double End Pedestal Grinder typically installed?

A: The grinder is designed for fixed or stationary installation, usually mounted securely on a pedestal or stand. This ensures stability, minimizes vibration, and allows for safe operation during heavy-duty grinding tasks.

Q: What benefits do the four heavy-duty precision bearings offer?

A: These precision bearings provide smooth, vibration-free operation, reducing maintenance and wear on the grinder. They also contribute to the tool's longevity and consistent grinding performance, even under continuous-duty use.

Q: When should I use a coolant tray with this grinder?

A: A coolant tray is optional and most beneficial during prolonged grinding tasks or when working on heat-sensitive materials. It helps regulate the temperature of both the grinding wheel and the workpiece, preventing overheating.

Q: Where is this grinder commonly used?

A: The Double End Pedestal Grinder is widely employed in manufacturing facilities, workshops, and industrial environments for tasks like grinding, deburring, and sharpening of metal workpieces.

Q: What are the size options for the grinding wheels?

A: The grinder supports grinding wheels ranging from 8 to 14 inches in diameter, allowing users to select an appropriate size based on their specific application and model requirements.

Q: How does the adjustable tool rest enhance usage?

A: The adjustable tool rest on both wheels offers greater flexibility and safety, allowing operators to position workpieces accurately for a variety of grinding and sharpening tasks.

Q: What is the noise level during operation, and why is it important?

A: The noise level remains below 85 dB(A) at 1 meter, ensuring a quieter and safer work environment. This is particularly important for maintaining operator comfort and adhering to industrial workplace noise regulations.
