Price 23000.0 INR/ Unit

MOQ : 1 Unit

Bench Type Drilling Machine Specification

  • Cutting Area
  • 40 mm diameter
  • Table Size
  • 300 x 300 mm
  • Noise Level
  • Low
  • Motor Power
  • 1.5 HP
  • Spindle Speed
  • Adjustable / Multi-speed
  • Diameter
  • Drilling Capacity 40 mm
  • Condition
  • New
  • Frequency
  • 50 Hz
  • Machine Type
  • Pillar Drill Machine
  • Features
  • Geared Square Model, Precision, Robust Structure
  • Dimension (L*W*H)
  • 700 x 400 x 1200 mm
  • Product Type
  • Bench Type Drilling Machine
  • Material
  • Cast Iron & Steel
  • Computerized
  • No
  • Automatic Grade
  • Manual
  • CNC Or Not
  • No
  • Control System
  • Lever Operated
  • Voltage
  • 220-240V / 3 Phase
  • Power
  • 1.5 HP
  • Power Source
  • Electric
  • Weight (kg)
  • Approx 120-150 kg
  • Capacity
  • 40 mm (1.5 inches)
  • Color
  • Green
  • Usage & Applications
  • Drilling, Tapping, Reaming of Metal and Other Materials
  • Model Name
  • RTD-23 C (Geared - Square Model)
  • Spindle Travel
  • 150 mm
  • Spindle Nose
  • MT-4
  • Table Adjustment
  • Manual with Rack & Pinion
  • Column Diameter
  • 85 mm
  • Max Distance Spindle to Base
  • 800 mm
  • Depth of Drilling
  • Up to 150 mm
  • Max Distance Spindle to Table
  • 500 mm
  • Chuck Capacity
  • Up to 13 mm (optional higher)
  • Finish
  • Machine Painted & Rustproof



About Bench Type Drilling Machine

Bench Type Drilling Machine manufacturer in Rajkot, Gujarat, India. Rajlaxmi Machine Tools offers Ramato, HMP & Roent bench drills for accurate metal drilling, engineering and fabrication applications.

Precision and Robust Construction

Built with cast iron and steel, the RTD-23 C ensures durability and stability. Its precision-geared square model delivers accurate drilling results, making it dependable for tasks requiring exact hole placement and consistent performance.


Versatile Operation and Adjustable Settings

The machine accommodates various drilling, tapping, and reaming jobs. With manual rack and pinion table adjustment and multi-speed spindle control, users can tailor settings to specific materials and requirements, enhancing versatility and ease of operation.


Safety, Efficiency, and Rustproof Finish

Designed for safety and reliability, the RTD-23 C features a low-noise operation and a rustproof finish. The lever-operated control system provides efficient and straightforward handling, promoting productivity in both industrial and workshop settings.

FAQ's of Bench Type Drilling Machine:


Q: How does the RTD-23 C Bench Type Drilling Machine operate for precision tasks?

A: The machine uses a geared square model and lever-operated control system to deliver accurate drilling, tapping, and reaming. The manual table adjustment with rack and pinion allows precise positioning, while adjustable spindle speeds accommodate various materials and task requirements.

Q: What are the main materials suitable for processing with this drilling machine?

A: The RTD-23 C is ideal for metalwork but also can be used for drilling, tapping, and reaming other materials such as plastics, providing versatility within manufacturing and workshop environments.

Q: When should I use the manual table adjustment feature?

A: Manual table adjustment via rack and pinion should be used whenever you need to reposition the workpiece closer or farther from the spindle to accommodate the size and height of your material for optimal drilling accuracy and comfort.

Q: Where is the RTD-23 C machine most commonly applied?

A: This drilling machine sees frequent use in workshops, manufacturing units, and industrial settings, especially where robust drilling capacities and reliable performance are necessary.

Q: What is the process for adjusting spindle speeds and why is it important?

A: Spindle speed can be adjusted using the machine's multi-speed settings, which is essential for matching the speed to the hardness and type of material being drilled. This ensures cleaner results and extends tool life.

Q: How can I benefit from the RTD-23 C's noise and rustproof features?

A: The low noise level improves workplace comfort, and the rustproof painted finish protects the machine, extending its operational lifespan even in harsh environments.

Q: Is computerized control available on this drilling machine?

A: No, the RTD-23 C operates solely on manual controls with lever operation, making it straightforward, reliable, and easy to maintain without computerized or CNC systems.
