AC Drive Belt Grinder Machine

Get a Price/Quote

AC Drive Belt Grinder Machine Specification

Rotation
Both Directions Possible with VFD

Model
Ramato Pedestal Polisher with VFD Drive

Product Type
Heavy Duty Pedestal Polisher with AC Drive

General Use
Pedestal Polishing and Grinding Operations

Material
Cast Iron Body, Mild Steel Pedestal

Type
Four Bearing Pedestal Polisher Grinder

Capacity
Heavy Duty Industrial Use

Weight (kg)
Approx. 120-150 kg (varies by model)

Computerized
No

Automatic
No, Manual Operation

CNC Or Not
Not CNC

Control System
AC Drive with VFD Control Panel

Grinding Wheel Size
Not Applicable (Compatible with various wheels as per requirement)

Grinding Wheel Speed
Variable, Controlled via VFD (Up to 3000 RPM, subject to model)

Grinding Length
Depends on Wheel/Workpiece Size

Floor Space
Approx. 700mm x 700mm

Spindle Speed
Variable via VFD (Up to 3000 RPM, subject to model)

Power
2 HP to 5 HP (as per model specification)

Voltage
415V AC, 3 Phase

Dimension (L*W*H)
Approx. 700mm x 700mm x 1100mm (varies as per model)

Feature
Four Bearing Construction for Heavy Duty, VFD/AC Drive for Speed Variation, Heavy Cast Iron Base

Color
Green/Custom finish

Mounting Type
Pedestal Mounted

Drive Type
Variable Frequency Drive (VFD) - Ensures Soft Start, Overload Protection, Speed Control

Protection
Motor Overload and Short Circuit Protection via Control Panel

Bearing Type
Heavy Duty Four Bearing Construction for Increased Durability

Noise Level
Low Vibration and Noise due to Four Bearing Design

Service Support
On-Site Installation and Support Available

Application
Industrial Metal Polishing, Grinding, Deburring, Tool Room, Workshop Maintenance

Control Panel Features
Digital Speed Display, Start/Stop Push Buttons, Emergency Stop, Speed Knob

Working Speed
Variable, Adjustable by Operator

AC Drive Belt Grinder Machine About

AC Drive Belt Grinder Machine manufacturer in India. Rajlaxmi Machine Tools, Rajkot, Gujarat offers Ramato, HMP & Roent belt grinders with variable conveyor speed and AC drive control.

Enhanced Durability and Stability

With a four bearing heavy-duty construction, this pedestal grinder minimizes vibration and noise for safer, smoother operation. The solid cast iron base and mild steel pedestal ensure the machine endures demanding industrial applications, providing long-term reliability in metalworking shops.

Precision Speed Control

Equipped with an advanced AC Drive and VFD control panel, operators can easily adjust spindle and grinding wheel speeds for different jobs. The digital speed display and manual control knob enable precise adjustment up to 3000 RPM, optimizing performance for various grinding and polishing requirements.

Safety and Convenience

This machine prioritizes user safety and convenience. It offers motor overload and short-circuit protection, an emergency stop button, and bi-directional rotation. On-site installation support and straightforward maintenance ensure the grinder integrates smoothly into industrial settings, enhancing productivity.

FAQ's of AC Drive Belt Grinder Machine:

Q: How can I adjust the working speed of the AC drive belt grinder machine?

A: You can easily adjust the working speed using the variable frequency drive (VFD) control panel. The speed control knob lets you select the desired RPM, which is also shown on the digital speed display, allowing for precise and safe operations.

Q: What kind of maintenance does the four bearing construction require?

A: The heavy-duty four bearing design is engineered for durability and minimal maintenance. Regular cleaning, periodic lubrication, and occasional inspection for wear ensure optimal performance and longevity.

Q: When is it necessary to use the emergency stop feature?

A: The emergency stop button should be used immediately if you encounter any unsafe situations, such as a jammed workpiece, unexpected noise, or electrical faults. This safety feature disconnects power quickly to prevent damage or injury.

Q: Where can this grinder be installed, and what space does it require?

A: Designed for industrial workshops, tool rooms, and maintenance areas, the grinder should be placed on stable flooring. It requires approximately 700mm x 700mm of floor space, with a height of around 1100mm, subject to the model specifications.

Q: What process advantages does the VFD-driven control system offer?

A: The variable frequency drive ensures smooth acceleration (soft start), precise speed control, and overload protection. This system boosts grinding quality, extends component life, and enhances operator safety.

Q: How does the machine accommodate different grinding wheels or workpieces?

A: The Ramato pedestal grinder is compatible with a variety of wheel sizes and types as per your application requirements. Its flexible mounting system and adjustable speed make it suitable for diverse grinding and polishing operations.

Q: What are the main benefits of choosing this four bearing pedestal polisher grinder?

A: Key benefits include high durability, low vibration, customizable speed, overload and short-circuit protection, and suitability for heavy-duty industrial tasks. The machine's robust construction, manual operation, and supportive on-site service make it a reliable asset for metalworking professionals.
